Description
Our Cure Tester and Purification kit have been designed for chemically postcuring and cleansing your 3D prints and for getting maximum biocompatibility and pass the cytotoxicity test.
Our Biocompatible 3D resins when properly cleansed with our Clear Detoxifier and Purification kit can pass the toxicity test.
Our cleansing system is ideal for biomedical applications, including dental and hearing systems, to ensure that biomedical devices are safe for use.
Follow first our Instructions for Use
Then, you can test the degree of cure with our Cure Tester:
Cure Tester
The cure test is based on applying a drop of the liquid dark color Cure Tester on the surface of the 3D print (exposed surface). After 5 minutes the liquid can be removed and cleaned to undertake visual evaluation of the chemically exposed surface. When there is no color difference between the exposed and the non exposed surface, the cure of the print is complete (full conversion from liquid to solid resin) , reflecting that there is not any residual free residual unreacted resin and the material is safe for use. In practice, 3D prints immediately after printing are never fully cured.
Normally, there is a high color difference between the chemically exposed surface (brownish color) and the non exposed surface (original reference color of the 3D print), indicating the existence of a relatively high concentration of unreacted resin, and that the print is not fully safe nor ready to be used for any sort of biomedical application.
This basic and easy to use test is ideal for monitoring if there is any residual uncured/unreacted resin in the 3D print and it is particularly useful for testing fast and cost efectively the safety of any 3D printed biomedical device.
A fully reacted 3D print can be easily analysed visually when there is not any increase of coloration of the exposed vs the unexposed printed surface. This qualitative test can be calibrated to make it cuantitative using reference values.
Chemical postcuring
Our Cure tester can also be used as Postcuring chemical agent because chemically reacts with any unreacted resin or monomer. This can be easily done by immersing or dipping completely the 3D prints inside a flask containing the Cure tester for 5-10 minutes at room temperature.
Any residual brown colored, reflect of the chemical burn out, will disappear after the prints are dipped for 5-10 minutes in our Purification kit, since chemically eliminates any residual byproducts left.
After cleaning the prints in the purification kit, prints have to be rinsed, as least twice, in water to eliminate any rest of the Purification kit.
This basic protocol helps to pass the cytotoxicity test when used with our Biocompatible 3Dresyns.
After light postcuring, the chemical purification process takes a total time of 10-20 minutes.
Post-curing & Purification. Our Cleansing Protocol in just few steps:
1. clean prints following our Instructions for Use IFU
2. dip prints inside a flask containing the Cure tester for 5-10 minutes at room temperature (avoid any contact of the Cure Tester with glycerine / glycerol to avoid any exothermic oxidation reaction)
3. dip prints in the Purification kit (not the Cleaning Fluid Bio) for 5-10 minutes to remove any residual brown color from residual byproducts left by the cure tester.
4. rinse prints in clean water, as least twice, to eliminate any rest of the Purification kit
Our Cure Tester and Purification kit are supplied as a kit, which contains 2 graduated beakers to inmerse the prints in the liquids , 1L bottle containing the Cure Tester (supplied as 10 grams of a dark powder) and 1L bottle containing the Purification kit (supplied as 50 grams of a white powder). Add 1 L of water to the original empty bottles containing the Cure Tester & Purification kit (mix well for full powder dissolution).
Read the MSDS (the kit contains corrosive chemicals), use gloves and goggles to avoid any contact with skin and eyes.
Note 1: this kit is ideal for clear and for colored resins formulated with chemical resistant colorants/pigments, otherwise colors may fade.
Note 2: 3D printed resins containingg leachables or extractables may fail the cytotoxicity test. The Cure Tester & Purification kit cannot reach the inside of either not fully cured prints, or prints based on not biocompatible 3d resins containing cytotoxic leachables or extractables.
Note 3: Injected molded RTV silicones use platinum catalysts, which are inhibited by some chemicals contained in 3D printed molds, leaving the surface of the silicone sticky or uncured. The use of our Cleaning Fluid, Cure Tester and Purification kit overcomes this common problem, by eliminating the inhibiting chemicals from the surface of 3D printed molds.
